CNC FANUC 15M
Technical details:
Pallet dimension: 800x800 mm
Pallet no. 2
Table rotation: 360 degree
Max weigth loaded on the table: 2000 kg
Max distance from table centre to spindle nose: 1300 mm
Max distance from table to spindle nose: 1050 mm
Max tool diameter: 110 mm
Max tool length: 500 mm
Travels X,Y,Z: 1350x1000x1000 mm
Rapid feedrates: 10 mt/min
Spindle taper: ISO 50
Spindle speed: 4500 rpm
Motor power 18.5 kw
Tool magazine: 90
